What Are Direct Thermal Labels?
Direct thermal labels are coated with a heat-sensitive chemical layer that turns black when exposed to the thermal print head. Unlike thermal transfer printing, direct thermal labels require no ribbon or ink — the print head directly activates the coating to produce sharp, clear images and text.
These labels are the industry standard for short-to-medium term applications such as shipping waybills, retail receipts, barcode inventory labels, and logistics tags where fast, reliable, and cost-effective printing is essential.
Specifications
- Material: Direct thermal paper / synthetic (PP/PET)
- Width: 25mm – 110mm (customizable)
- Length: Continuous roll or die-cut labels
- Adhesive: Permanent, removable, or freezer-grade
- Core Size: 25mm, 40mm, or 76mm
- Roll Diameter: Max 200mm
Common Sizes
- 3 1/8″ (80mm) x 170′ (52m) / 263′ (80m)
- 2 1/4″ (58mm) x 170′ (52m) / 263′ (80m)
- 1 1/2″ (40mm) x 170′ (52m) / 263′ (80m)
- Custom sizes available per customer requirements
Features & Advantages
- No ribbon required: Lower cost, simplified printing process
- High-speed printing: Ideal for logistics and high-volume retail
- Sharp imaging: Excellent print clarity for barcodes and text
- Wide compatibility: Works with Zebra, Godex, TSC, and all major thermal printer brands
- Eco-friendly: No ink, toner, or ribbon waste
- Low maintenance: Fewer moving parts, reduced downtime
Application Scenarios
- 📦 Logistics & Shipping (waybills, shipping labels)
- 🏪 Retail & POS (receipts, price tags)
- 📋 Warehouse & Inventory (barcode labels, bin tags)
- 🚚 Transportation & Logistics (parcel labels)
- 🏥 Healthcare (sample labels, patient ID wristbands)
- 📦 E-commerce (fulfillment labels)
Storage & Handling
Direct thermal labels are sensitive to heat, light, and moisture. For best print quality and image longevity:
• Store in a cool, dry place (15–25°C / 59–77°F)
• Avoid direct sunlight and UV exposure
• Use within 1 year of manufacture
• Keep away from plasticizers and PVC materials
Customization Options
- Custom widths, lengths, and die-cut shapes
- Pre-printed brand logos or static text (flexo/letterpress)
- Color top coating (brand colors available)
- Specialized adhesive formulas (freezer-grade to -40°C, high-tack)
- Pattern gumming (adhesive-free zones for easy peeling)
- Minimum Order Quantity (MOQ): 1 roll
Quality & Certifications
- ✅ ISO 9001:2015 Certified
- ✅ FDA Approved (food contact materials)
- ✅ REACH & RoHS Compliant
- ✅ FSC Certified (sustainable paper)
